| PRODUCT SPECIFICATIONS |
|
| Weight(KG) |
1160KG |
| Length(MM) |
5358 |
| Upper connection type(INCH) |
NC50/51/2FH |
| Lower connection type(INCH) | 4 1/2REG/65/8REG |
| Lobe |
7：8 |
| Stage | 5 |
| Use max temperature (C) | Normal temperature |
| Distance from bit to bending point (MM): | 1540 (Fixed) |
Stabilizer type
|
NO |
| OPERATING PARAMETERS |
|
| Motor displacement (L/S) | 20-39 |
| Rotary Speed (RPM) | 84-168 |
| Working torque (NM） | 7895 |
| Max torque (NM) | 11160 |
| Work pressure drop (MPA) | 4.4 |
| Max pressure drop (MPA) | 6.22 |
| Weight on bit (KN) | 100 |
| Max WOB (KN) | 170 |
| Power (KW) | 176 |
